Description
Develon DX225LC-7X
Specifications
Manufacturer
Develon
Model
DX225LC-7X
Year
2026
Category
Excavators
Subcategory
Crawler Excavators
Rated Flywheel Power (Gross)
173 hp @ 1800 rpm
Rated Horse Power (Net)
162.3 hp @ 1800 rpm
Max. Torque (Net)
593 lbf ft @ 1400 rpm
Engine Emissions Tier (Epa)
Tier 4
Swing Performance: Max Swing Torque
60757 lbf ft
Engine Coolant
7.85 gal
Engine Oil
7.13 gal
Swing Performance: Max Swing Speed (At Efficiency)
10.9 rpm
Model
DL06V
Engine After Treatment
CEGR+DOC+SCR with DEF
Engine Make
Doosan
Engine Number Of Cylinders
6
Engine Displacement
359 in³
Upper Rollers: Quantity Per Side
2
Lower Rollers: Quantity Per Side
8
Track Link: Track Gauge
7' 10"
Travel Performance: Traction Force (Highest Value)
60715 lbf
Travel Performance: Traveling Speed - High (/Xxx)
3.42 mph
Travel Performance: Traveling Speed - Low (Xxx/)
1.86 mph
Travel Performance: Gradeability
35° @ 70 %
Operating Weight
52029 lb
Max Digging Reach (Ground)
31' 9"
Max Digging Height
31' 6"
Max Digging Depth
21' 7"
Bucket Digging Force - Pressure Up
3709 lbf
Arm Digging Force - Pressure Up
2585 lbf
Arm Digging Force - Normal
2462 lbf
Fuel Tank
103.56 gal
Hydraulic Tank
34.61 gal
Noise Level: Guaranteed Sound Power Level
102 dBA
Noise Level: Operator
70 dBA
Standard Bucket Size
1.2 yd³
Lifting Capacity Over Front @ Horizontal Distance - 10 Ft Above Ground
18301 lb @ 20.01 ft
Lifting Capacity Over Front @ Horizontal Distance - Ground Level
22190 lb @ 20.01 ft
Lifting Capacity Over Front @ Horizontal Distance - 10 Ft Below Ground
20860 lb @ 20.01 ft
Track Length
14' 7"
Standard Boom Length
18' 8"
Standard Arm Length
9' 6"
Shoe Width
2' 7"
Shipping Height - Hose (With Attachment)
9' 10"
Overall Height Over Cab
9' 9"
Max Loading Height
22' 4"
Shipping Length (Without Attachment)
31' 4"
Ground Clearance
1' 5"
Shipping Width (Standard)
10' 5"
Main Pump: Max. Flow Rate (Each)
55.48 gal/min
Main Pump: Displacement
7.14 in³/rev
Main Pump: Quantity
2
Main Pump: Main Relief Pressure
4978 psi
Ground Pressure
5.26 psi
Hydraulic System
60.76 gal
