Description
This track loader is pound for pound the highest performing machine in our lineup. Perfect for landscaping, rental and snow removal, the RT-40 wins with muscle and hustle.With a compact frame and maximum power, the RT-40 provides a productive alternative to walk-behind and stand-on mini skid-steer loaders. And with its reliability, serviceability and comfort it’s ideal for homeowners and contractors looking to accomplish a lot in small spaces.
Specifications
Manufacturer
ASV
Model
RT-40
Year
2025
Category
Loaders
Subcategory
Compact Track Loaders
Operating Weight
4175 lbs
Rated Operating Capacity @ 35%
931 lbs
Ground Pressure
3.5 psi
Tipping Load
2660 lbs
Max Travel Speed
7.1 mph
Height to Bucket Pin
101 in
Rear Angle of Departure
44 Degrees
Bucket Roll Back at Ground Level
18.2 Degrees
Ground Clearance
15 in
Overall Length with Bucket
157 in
Reach at Dump Height
24 in
Nominal Charge
12 V
Battery
525 CCA
Maximum Dump Angle at Full Height
43 Degrees
Engine Power
37.5 hp
Displacement
111.4 in
Gross Horsepower
37.5 hp
Torque Peak
84.5 ft lb
Rated Operating Capacity @ 50%
1330 lbs
Fuel Tank
13 gal
Hydraulic Tank
3.5 gal
Engine Coolant
1.8 gal
Engine Oil (Including Filter)
7.4 quarts
Full Length
112.7 in
Machine Height
75.5 in
Width
48.3 in
Arm-Up Height
101 in
System Pressure Max Low
3000 psi
Flat Faced Couplers
5/8 in
Auxiliary Pump Flow
13.3 gpm
Track Width
11 in
Length of Track on the Ground
55 in
Ground Contact Area
1210 in
Roller Wheels
12
Roller Wheel Diameter
10 in
Quick Enquiry
Loaders ASV Items for Sale Lowell
Find this ASV RT-40 at RONSON EQUIPMENT COMPANY, LLC
