Description
The SK260LC-11 is one of the new KOBELCO excavators engineered to bring together superior performance and design. This new Generation -11 machine is equipped with a Yanmar Tier IV Final compliant engine with 194 hp, which has a higher torque value increasing performance. The KOBELCO SK260LC-11 is more durable than ever and able to withstand the rigors of the toughest job sites. The revolutionary technology provides a 10-inch high resolution screen the operator can customize to provide all the input they need for the job. The SK260LC-11 has many exclusive operator comforts like a heated air ride suspension seat, multi vent air conditioner, ergonomic adjustable lever angles and joystick, interior LED lights and a tilting left console for easy entry and exit. All to promote productivity and operator safety.
Specifications
Manufacturer
Kobelco
Model
SK260LC-11
Year
2025
Category
Excavators
Subcategory
Conventional Excavators
Number of Main Pumps
2
Travel Speed
3.6 mph (5.8 kph) / 2.2 mph (3.6 kph)
Drawbar Pulling Force
54,600 lbf (243 kN)
Operating Weight
60,200 lbs (27,300 kg)
Bucket Digging Force
42,000 lbf (187 kN)
Arm Crowding Force
30,100 lbf (134 kN)
Engine Power
178 hp (133 kW)
Overall Height (to top of boom)
10' 11" (3,320 mm)
Overall Width
11' 1" (3,390 mm)
Ground Clearance of Rear End
3' 7" (1,090 mm)
Ground Clearance
17.3" (440 mm)
Tail Swing Radius
10' 2" (3,100 mm)
Distance From Center of Swing To Rear End
10' 1" (3,070 mm)
Tumbler Distance
12' 8" (3,850 mm)
Track Gauge
8' 6" (2,590 mm)
Shoe Width
31.5 (800 mm)
Overall Width of Upperstructure
10' 3" (3,120 mm)
Max Digging Reach
33' 10" (10,300 mm)
Max Digging Reach At Ground Level
33' 3" (10,140 mm)
Max Digging Depth
23' (7,000 mm)
Max Digging Height
32' 1" (9,790 mm)
Max Dumping Clearance
22' 7" (6,880 mm)
Max Vertical Wall Digging Depth
20' 2" (6,150 mm)
Min Swing Radius
12' 10" (3,910 mm)
Digging Depth For 8 Feet Flat Bottom
22' 4" (6,820 mm)
Model
Yanmar 4TNV107FTT
Power Output
208 hp (155 kW)
Power Output a
194 hp (145 kW)
Max Torque
594 lbf (805 Nm)
Displacement
278.7 in³ (4.567 ltr)
Fuel Tank
106.5 gallons (US) (403 ltr)
