Description
KOBELCO'S new -11 Series excavators have been engineered to provide greater efficiency and productivity along with increased speed. The new KOBELCO SK210LC-11 is equipped with a Yanmar Tier IV Final compliant engine which has a higher torque value providing bucket digging force of 35,300 lbs and lifting capacity of 16,660 lbs The new design also offers premier operator safety and comfort features including a high resolution 3-sides camera system with a high resolution 10-inch monitor. A jog dial provides the operator with the selected information. The cab even has a heated air ride suspension seat, multi-vent air conditioner, and adjustable height joysticks to fit the operator.
Specifications
Manufacturer
Kobelco
Model
SK210LC-11
Year
2025
Category
Excavators
Subcategory
Conventional Excavators
Number of Main Pumps
2
Travel Speed
3.7 mph (6 kph) / 2.2 mph (3.6 kph)
Drawbar Pulling Force
51,300 lbf (228 kN)
Operating Weight
50,000 lbs (22,700 kg)
Tail Swing Radius
9' 7" (2,910 mm)
Ground Clearance of Rear End
3' 6" (1,060 mm)
Ground Clearance
16.7" (425 mm)
Digging Depth For 8 Feet Flat Bottom
21' 4" (6,520 mm)
Bucket Digging Force
35,300 lbf (157 kN)
Arm Crowding Force
25,200 lbf (112 kN)
Max Digging Reach
32' 6" (9,900 mm)
Max Digging Reach At Ground Level
31' 11" (9,730 mm)
Max Digging Depth
22' (6,700 mm)
Max Digging Height
31' 11" (9,720 mm)
Max Dumping Clearance
22' 8" (6,910 mm)
Max Vertical Wall Digging Depth
20' (6,100 mm)
Min Swing Radius
11' 8" (3,550 mm)
Track Gauge
7' 10" (2,390 mm)
Overall Height (to top of boom)
10' 5" (3,170 mm)
Overall Width
10' 5" (3,180 mm)
Distance From Center of Swing To Rear End
9' 6" (2,900 mm)
Tumbler Distance
12' (3,660 mm)
Shoe Width
31.1 (790 mm)
Overall Width of Upperstructure
9' 4" (2,850 mm)
Model
Yanmar 4TN107FTT
Power Output
170 hp (127 kW)
Power Output a
160 hp (119 kW)
Displacement
278.7 in³ (4.567 ltr)
Fuel Tank
84.5 gallons (US) (320 ltr)
Max Torque
594 lbf (805 Nm)
Engine Power
160 hp (119 kW)
