Description
Develon DX300LL-5
Specifications
Manufacturer
Develon
Model
DX300LL-5
Year
2025
Category
Logging Equipment
Subcategory
Log Loaders
Engine Rated Flywheel Power (Gross)
270.9 hp @ 1,800 rpm
Engine Rated Horse Power (Net)
266.5 hp @ 1,800 rpm
Engine Max. Torque (Net)
940 lbf ft @ 1,300 rpm
Undercarriage Upper Rollers: Quantity Per Side
2
Undercarriage Track Length
16' 1"
Undercarriage Track Link: Track Gauge
6' 6"
Swing Mechanism Swing Performance: Max Swing Torque
34718 lbf ft
Swing Mechanism Swing Performance: Max Swing Speed (At Efficiency)
9.88 rpm
Travel System/Drive Mechanism Travel performance: Traction Force (Highest Value)
201 lbf ft @ 80 %
Travel System/Drive Mechanism Travel performance: Traveling Speed - Low (XXX/)
1.93 mph
Travel System/Drive Mechanism Travel performance: Traveling Speed - High (/XXX)
2.86 mph
Travel System/Drive Mechanism Travel performance: Gradeability
35° @ 70 %
Weights Operating Weight
81,703 lb
Weights Standard Boom Length
20.67 ft
Weights Standard Arm Length
12.83 ft
Weights Shoe Width
2' 3"
Refill Capacities Fuel Tank
132.09 gal
Refill Capacities Engine Coolant
12.94 gal
Refill Capacities Engine Oil
9.51 gal
Refill Capacities Hydraulic Tank
73.97 gal
Environment Noise Level: Operator
69 dBA
Lift Capacity Lifting Capacity over front @ Horizontal Distance - 10 ft Above Ground
31,061 lb @ 14.99 ft
Lift Capacity Lifting Capacity over front @ Horizontal Distance - Ground Level
24,791 lb @ 0 ft
Lift Capacity Lifting Capacity over front @ Horizontal Distance - 10 ft Below Ground
24,989 lb @ 15.09 ft
Dimensions Shipping Length (Without Attachment)
18' 8"
Dimensions Shipping Width (Standard)
11' 9"
Dimensions Overall Height Over Cab
15' 3"
Dimensions Shipping Height - Hose (With Attachment)
47' 4"
Hydraulic System Main Pump: Displacement
567.52 in³/rev
Hydraulic System Control Valve: Relief Valve Pressure (Normal)
4,694 psi
Hydraulic System Control Valve: Relief Valve Pressure (Boost)
4,978 psi
Hydraulic System Main Pump: Max. Flow Rate (each)
65.51 gal/min
