Description
Develon DL550-7
Specifications
Manufacturer
Develon
Model
DL550-7
Year
2025
Category
Loaders
Subcategory
Wheel Loader
Model
DC13
Rated Flywheel Power (Gross)
380 hp @ 1800 rpm (SAE-J1995)
Rated Horse Power (Net)
380 hp @ 1800 rpm
Max. Torque (Net)
1302 lbf ft @ 1300 rpm
Engine Emissions Tier (Epa)
Tier 4
Engine After Treatment
DOC + SCR
Engine Make
Scania
Engine Number Of Cylinders
6
Engine Displacement
452 in³
Tire Size
29.5R25 (L3)
Travel Performance: Gradeability
58 ° @ 30 %
Traveling Performance: Max. Tractive Effort
72091 lb
Operating Weight
70599 lb
Bucket Capacity
6.8 yd³
Static Tipping Load (Straight)
53273 lb
Static Tipping Load (Full Turn)
47042 lb
Breakout Force
56202 lbf
Speeds Fwd
4
Speeds Rev
3
Travel Speed Forward - 1St Gear
3.79 mph
Travel Speed Forward - 4Th Gear
23.18 mph
Final Drive
Planetary
Differential Type
Hydraulic Locking
Fuel Tank
116.5 gal
Cooling System
14.27 gal
Def / Ad Blue Tank
15.85 gal
Tread Width
7' 11"
Bucket Width
11' 2"
Hinge Pin Height
15' 7"
Dump Reach At 45° (Fully Raised)
4' 4"
Dump Height At 45° (Fully Raised)
11' 3"
Overall Height
12' 7"
Overall Length
32' 5"
Wheel Base
12' 1"
Ground Clearance
1' 6"
External Turning Radius At Bucket Edge
24' 6"
Rear Axle Oscillation
20 °
Digging Depth
3.0"
Main Pump: Displacement
6.1 in³/rev
System Pressure: Work
3626 psi
Main Pump: Max. Flow Rate (Each)
55.5 gal/min
Main Pump: Quantity
1
Main Pump: Main Relief Pressure
3626 psi
Hydraulic System
63.93 gal
Hydraulic Tank
63.93 gal
