Description
Develon DX85R-3
Specifications
Manufacturer
Develon
Model
DX85R-3
Year
2025
Category
Excavators
Subcategory
Mini Excavators
Rated Flywheel Power (Gross)
59.4 hp @ 2,100 rpm (SAE-J1995)
Rated Horse Power (Net)
58.6 hp @ 2,100 rpm
Max. Torque (Net)
178 lbf ft @ 1,365 rpm
Engine Emissions Tier (Epa)
T4
Swing Performance: Max Swing Torque
14104 lbf ft
Engine Rated Flywheel Power (Gross)
59.4 hp @ 2,100 rpm (SAE-J1995)
Engine Rated Horse Power (Net)
58.6 hp @ 2,100 rpm
Engine Max. Torque (Net)
178 lbf ft @ 1,365 rpm
Engine Engine Emissions Tier (EPA)
T4
Travel Performance: Gradeability
58°
Operating Weight
18,960 lb
Noise Level: Guaranteed Sound Power Level
98 dBA
Noise Level: Operator
71 dBA
Upper Rollers: Quantity Per Side
1
Track Link: Track Gauge
6' 0"
Travel Performance: Traction Force (Highest Value)
48 lbf ft
Travel Performance: Traveling Speed - Low (Xxx/)
1.68 mph
Travel Performance: Traveling Speed - High (/Xxx)
2.92 mph
Undercarriage Track Length
9' 3"
Undercarriage Track Link: Track Gauge
6' 0"
Swing Mechanism Swing Performance: Max Swing Speed (At Efficiency)
9.5 rpm
Travel System/Drive Mechanism Travel performance: Traction Force (Highest Value)
48 lbf ft
Travel System/Drive Mechanism Travel performance: Traveling Speed - Low (XXX/)
1.68 mph
Travel System/Drive Mechanism Travel performance: Traveling Speed - High (/XXX)
2.92 mph
Weights Operating Weight
18,960 lb
Weights Standard Boom Length
11.09 ft
Weights Standard Arm Length
7.38 ft
Weights Standard Bucket Size
0.37 yd³
Weights Shoe Width
1' 5"
Working Range Max Digging Reach (Ground)
23' 11"
Working Range Max Digging Depth
15' 6"
Working Range Max Loading Height
16' 4"
Digging Force (ISO) Arm Digging Force - Normal
8,069 lb
Digging Force (ISO) Arm Digging Force - Pressure up
8,069 lb
Digging Force (ISO) Bucket Digging Force - Pressure up
14,509 lb
Environment Noise Level: Guaranteed Sound Power Level
98 dBA
Environment Noise Level: Operator
71 dBA
Lift Capacity Lifting Capacity over front @ Horizontal Distance - 10 ft Below Ground
5,020 lb @ 10 ft
Standard Boom Length
11.09 ft
Standard Arm Length
7.38 ft
Standard Bucket Size
0.37 yd³
Overall Height Over Cab
8' 7"
Max Digging Depth
15' 6"
Max Loading Height
16' 4"
Track Length
9' 3"
Shoe Width
1' 5"
Shipping Height - Hose (With Attachment)
8' 1"
Shipping Length (Without Attachment)
20' 6"
Shipping Width (Standard)
7' 6"
Max Digging Reach (Ground)
23' 11"
Bucket Digging Force - Pressure Up
14,509 lb
Arm Digging Force - Normal
8,069 lb
Lifting Capacity Over Front @ Horizontal Distance - 10 Ft Above Ground
2,380 lb @ 20 ft
Lifting Capacity Over Front @ Horizontal Distance - Ground Level
1,810 lb @ 20 ft
Dimensions Shipping Height - Hose (With Attachment)
8' 1"
Dimensions Shipping Length (Without Attachment)
20' 6"
Dimensions Shipping Width (Standard)
7' 6"
Dimensions Overall Height Over Cab
8' 7"
Control Valve: Relief Valve Pressure (Normal)
4,054 psi
Control Valve: Relief Valve Pressure (Boost)
3,983 psi
Hydraulic System Control Valve: Relief Valve Pressure (Normal)
4,054 psi
Hydraulic System Control Valve: Relief Valve Pressure (Boost)
3,983 psi
