Description
Develon DX255LC-5
Specifications
Manufacturer
Develon
Model
DX255LC-5
Year
2025
Category
Excavators
Subcategory
Crawler Excavators
Rated Flywheel Power (Gross)
189.1 hp @ 1,900 rpm (SAE J1995)
Rated Horse Power (Net)
185.1 hp @ 1,900 rpm (SAE J1349)
Max Torque (Net)
593 lbf ft @ 1,400 rpm
Engine Emissions Tier (Epa)
T4
Engine Coolant
7.4 gal
Engine Oil
7.13 gal
Upper Rollers: Quantity Per Side
2
Lower Rollers: Quantity Per Side
10
Swing Performance: Max Swing Torque
71462 lbf ft
Swing Performance: Max Swing Speed (At Efficiency)
10.01 rpm
Travel Performance: Traction Force (Highest Value)
1,952,878 lbf @ 100
Travel Performance: Traveling Speed - Low (Xxx/)
1.99 mph
Travel Performance: Traveling Speed - High (/Xxx)
3.48 mph
Travel Performance: Gradeability
70°
Operating Weight
57,752 lb
Arm Digging Force - Pressure up
2,878 lbf
Bucket Digging Force - Pressure up
4,024 lbf
Arm Digging Force - Normal
2,720 lbf
Fuel Tank
110.95 gal
Noise Level: Guaranteed Sound Power Level
103 dBA
Noise Level: Operator
70 dBA
Lifting Capacity over front @ Horizontal Distance - 10 ft Above Ground
18,080 lb @ 20 ft
Lifting Capacity over front @ Horizontal Distance - Ground Level
20,050 lb @ 20 ft
Lifting Capacity over front @ Horizontal Distance - 10 ft Below Ground
19,950 lb @ 20 ft
Track Length
15' 2"
Track Link: Track Gauge
8' 6"
Standard Boom Length
19.36 ft
Standard Arm Length
9.84 ft
Standard Bucket Size
1.44 yd³
Shoe Width
2' 7"
Shipping Height - Hose (With Attachment)
10' 5"
Shipping Length (Without Attachment)
33' 0"
Shipping Width (Standard)
11' 1"
Overall Height Over Cab
9' 9"
Max Digging Reach (Ground)
32' 9"
Max Digging Depth
22' 4"
Max Loading Height
23' 0"
Main Pump: Displacement
7.02 in³/rev
Control Valve: Relief Valve Pressure (Normal)
4,978 psi
Control Valve: Relief Valve Pressure (Boost)
5,263 psi
Main Pump: Max Flow Rate (each)
57.85 gal/min
Hydraulic System
73.97 gal
Hydraulic Tank
63.4 gal
