Description
Develon DL250-7
Specifications
Manufacturer
Develon
Model
DL250-7
Year
2026
Category
Loaders
Subcategory
Wheel Loader
Model
DL06
Rated Flywheel Power (Gross)
171.7 hp @ 2100 rpm (SAE-J1995)
Rated Horse Power (Net)
171.7 hp @ 2100 rpm
Max. Torque (Net)
593 lbf ft @ 1400 rpm
Engine Emissions Tier (Epa)
Tier 4
Engine After Treatment
CEGR+DOC+SCR with DEF
Engine Make
Doosan
Engine Number Of Cylinders
6
Engine Displacement
359 in³
Total Cycle Time
11.4 s (±3 s)
Tire Size
20.5R25, L3
Travel Performance: Gradeability
30 ° @ 58 %
Traveling Performance: Max Tractive Effort
29101 lb
Operating Weight
30527 lb
Bucket Capacity
3.27 yd³
Static Tipping Load (Straight)
23973 lb
Static Tipping Load (Full Turn)
21134 lb
Breakout Force
23987 lbf
Speeds Fwd
4
Speeds Rev
3
Travel Speed Forward - 1St Gear
3.98 mph
Travel Speed Forward - 4Th Gear
23.3 mph
Final Drive
Planetary
Differential Type
Limited Slip
Fuel Tank
62.08 gal
Cooling System
8.98 gal
Def / Ad Blue Tank
7.93 gal
Tread Width
6' 8"
Bucket Width
8' 11"
Hinge Pin Height
12' 7"
Dump Reach At 45° (Fully Raised)
3' 6"
Dump Height At 45° (Fully Raised)
9' 2"
Overall Height
10' 10"
Overall Length
24' 6"
Wheel Base
10' 0"
Ground Clearance
1' 5"
External Turning Radius At Bucket Edge
19' 10"
Rear Axle Oscillation
22 °
Digging Depth
2.0"
Main Pump: Displacement
4.52 in³/rev
System Pressure: Work
3844 psi
Main Pump: Max. Flow Rate (Each)
40.95 gal/min
Main Pump: Quantity
1
Main Pump: Main Relief Pressure
3843 psi
Hydraulic System
31.7 gal
Hydraulic Tank
22.45 gal
