Description
Develon DX350LC-7
Specifications
Manufacturer
Develon
Model
DX350LC-7
Year
2026
Category
Excavators
Subcategory
Crawler Excavators
Model
DL08
Rated Flywheel Power (Gross)
285.6 hp @ 1800 rpm
Rated Horse Power (Net)
280.3 hp @ 1800 rpm
Max. Torque (Net)
940 lbf ft @ 1300 rpm
Engine Emissions Tier (Epa)
Tier 4
Engine After Treatment
CEGR+DOC+SCR with DEF
Engine Make
Doosan
Engine Name
DL08
Engine Number Of Cylinders
6
Engine Displacement
466 in³
Swing Performance: Max Swing Speed (At Efficiency)
9.3 rpm
Engine Coolant
14.82 gal
Engine Oil
11.1 gal
Upper Rollers: Quantity Per Side
2
Lower Rollers: Quantity Per Side
9
Travel Performance: Traveling Speed - Low (Xxx/)
2.11 mph
Travel Performance: Traveling Speed - High (/Xxx)
3.48 mph
Travel Performance: Gradeability
35 ° @ 70 %
Operating Weight
82416 lb
Standard Bucket Size
1.95 yd³
Max Digging Reach (Ground)
35' 11"
Max Digging Height
33' 10"
Max Digging Depth
24' 8"
Arm Digging Force - Pressure Up
41590 lbf
Bucket Digging Force - Pressure Up
57101 lbf
Arm Digging Force - Normal
39342 lbf
Fuel Tank
158.5 gal
Noise Level: Guaranteed Sound Power Level
105 dBA
Noise Level: Operator
71 dBA
Track Length
16' 3"
Ground Clearance
1' 6"
Standard Boom Length
21' 3"
Standard Arm Length
10' 6"
Shoe Width
2' 7"
Shipping Length (Without Attachment)
37' 1"
Shipping Width (Standard)
11' 5"
Max Loading Height
23' 6"
Main Pump: Displacement
12.2 in³/rev
Main Pump: Max. Flow Rate (Each)
92.46 gal/min
Main Pump: Quantity
2
Main Pump: Main Relief Pressure
5076 psi
Ground Pressure
7.68 psi
Hydraulic System
100.39 gal
Hydraulic Tank
64.19 gal
