Description
With their wider stance and increased clearance, KOBELCO High & Wide excavators can tackle jobs usually reserved for bigger machines – including forestry work, craning large pipe and loading out trucks. The SK260LC-11 H&W features an overall width of 11’ 8”, making it stable under the heaviest of loads. Plus, it offers all the standard features you expect from a KOBELCO, including independent travel, swing flashers and premier operator comforts.
Specifications
Manufacturer
Kobelco
Model
SK260LC-11 H&W
Year
2025
Category
Excavators
Subcategory
Specialty Excavators
Number of Main Pumps
2
Travel Speed
3.6 mph (5.8 kph) / 2.2 mph (3.6 kph)
Drawbar Pulling Force
54,600 lbf (243 kN)
Operating Weight
65,000 lbs (29,500 kg)
Bucket Digging Force
42,000 lbf (187 kN)
Arm Crowding Force
30,100 lbf (134 kN)
Engine Power
194 hp (145 kW)
Overall Height (to top of boom)
11' 3" (3,440 mm)
Overall Width
11' 8" (3,550 mm)
Ground Clearance of Rear End
4' 8" (1,430 mm)
Ground Clearance
31" (780 mm)
Tail Swing Radius
10' 2" (3,100 mm)
Distance From Center of Swing To Rear End
10' 1" (3,070 mm)
Tumbler Distance
12' 5" (3,790 mm)
Track Gauge
9' 4" (2,850 mm)
Shoe Width
27.6 (700 mm)
Overall Width of Upperstructure
10' 3" (3,120 mm)
Model
Yanmar 4TNV107FTT
Power Output
208 hp (155 kW)
Power Output a
194 hp (145 kW)
Max Torque
594 lbf (805 Nm)
Displacement
278.7 in³ (4.567 ltr)
Fuel Tank
106.5 gallons (US) (403 ltr)
