Description
Develon DX63-3
Specifications
Manufacturer
Develon
Model
DX63-3
Year
2025
Category
Excavators
Subcategory
Mini Excavators
Rated Flywheel Power (Gross)
59.4 hp @ 2,100 rpm
Rated Horse Power (Net)
58.6 hp @ 2,100 rpm
Max. Torque (Net)
178 lbf ft @ 1,365 rpm
Engine Emissions Tier (Epa)
T4
Swing Performance: Max Swing Torque
9526 lbf ft
Engine Rated Flywheel Power (Gross)
59.4 hp @ 2,100 rpm
Engine Rated Horse Power (Net)
58.6 hp @ 2,100 rpm
Engine Max. Torque (Net)
178 lbf ft @ 1,365 rpm
Engine Engine Emissions Tier (EPA)
T4
Travel Performance: Gradeability
58°
Operating Weight
13,779 lb
Noise Level: Guaranteed Sound Power Level
97 dBA
Noise Level: Operator
73 dBA
Upper Rollers: Quantity Per Side
1
Track Link: Track Gauge
5' 2"
Travel Performance: Traction Force (Highest Value)
41 lbf ft
Travel Performance: Traveling Speed - Low (Xxx/)
1.68 mph
Travel Performance: Traveling Speed - High (/Xxx)
2.73 mph
Undercarriage Upper Rollers: Quantity Per Side
1
Undercarriage Track Length
8' 2"
Undercarriage Track Link: Track Gauge
5' 2"
Swing Mechanism Swing Performance: Max Swing Speed (At Efficiency)
9.4 rpm
Travel System/Drive Mechanism Travel performance: Traction Force (Highest Value)
41 lbf ft
Travel System/Drive Mechanism Travel performance: Traveling Speed - Low (XXX/)
1.68 mph
Travel System/Drive Mechanism Travel performance: Traveling Speed - High (/XXX)
2.73 mph
Weights Operating Weight
13,779 lb
Weights Standard Boom Length
9.51 ft
Weights Standard Arm Length
6.23 ft
Weights Standard Bucket Size
0.23 yd³
Weights Shoe Width
1' 3"
Working Range Max Digging Reach (Ground)
20' 5"
Working Range Max Digging Depth
13' 6"
Working Range Max Loading Height
13' 11"
Digging Force (ISO) Arm Digging Force - Normal
5,765 lb
Digging Force (ISO) Arm Digging Force - Pressure up
5,765 lb
Digging Force (ISO) Bucket Digging Force - Pressure up
9,731 lb
Environment Noise Level: Guaranteed Sound Power Level
97 dBA
Environment Noise Level: Operator
73 dBA
Standard Boom Length
9.51 ft
Standard Arm Length
6.23 ft
Standard Bucket Size
0.23 yd³
Overall Height Over Cab
8' 4"
Max Digging Depth
13' 6"
Max Loading Height
13' 11"
Track Length
8' 2"
Shoe Width
1' 3"
Shipping Height - Hose (With Attachment)
7' 9"
Shipping Length (Without Attachment)
18' 7"
Shipping Width (Standard)
6' 5"
Max Digging Reach (Ground)
20' 5"
Arm Digging Force - Pressure Up
5,765 lb
Bucket Digging Force - Pressure Up
9,731 lb
Arm Digging Force - Normal
5,765 lb
Lifting Capacity Over Front @ Horizontal Distance - 10 Ft Above Ground
1,800 lb @ 15 ft
Lifting Capacity Over Front @ Horizontal Distance - Ground Level
1,580 lb @ 15 ft
Lifting Capacity Over Front @ Horizontal Distance - 10 Ft Below Ground
2,870 lb @ 9.72 ft
Dimensions Shipping Height - Hose (With Attachment)
7' 9"
Dimensions Shipping Length (Without Attachment)
18' 7"
Dimensions Shipping Width (Standard)
6' 5"
Dimensions Overall Height Over Cab
8' 4"
Control Valve: Relief Valve Pressure (Normal)
3,342 psi
Control Valve: Relief Valve Pressure (Boost)
3,271 psi
Hydraulic System Control Valve: Relief Valve Pressure (Normal)
3,342 psi
Hydraulic System Control Valve: Relief Valve Pressure (Boost)
3,271 psi
