Description
Develon DX35-5
Specifications
Manufacturer
Develon
Model
DX35-5
Year
2025
Category
Excavators
Subcategory
Mini Excavators
Rated Flywheel Power (Gross)
33.5 hp @ 2,400 rpm (SAE-J1995)
Rated Horse Power (Net)
31.2 Hp @ 2,400 Rpm
Max. Torque (Net)
81 lbf ft @ 1,600 Rpm
Engine Emissions Tier (Epa)
Tier 4
Engine Rated Flywheel Power (Gross)
33.5 hp @ 2,400 rpm (SAE-J1995)
Engine Rated Horse Power (Net)
31.2 hp @ 2,400 rpm
Engine Max. Torque (Net)
81 lbf ft @ 1,600 rpm
Engine Engine Emissions Tier (EPA)
Tier 4
Lower Rollers: Quantity Per Side
4
Swing Performance: Max Swing Speed (At Efficiency)
8.6 rpm
Travel Performance: Traction Force (Highest Value)
7658 lbf ft
Travel Performance: Traveling Speed - Low (Xxx/)
1.6 Mph
Travel Performance: Traveling Speed - High (/Xxx)
2.9 Mph
Travel Performance: Gradeability
30°
Operating Weight
8,193 lb
Max Digging Reach (Ground)
17' 1"
Arm Digging Force - Pressure Up
4,859 lb
Bucket Digging Force - Pressure Up
6,968 lb
Undercarriage Lower Rollers: Quantity Per Side
4
Undercarriage Track Length
6' 9"
Travel System/Drive Mechanism Travel performance: Traction Force (Highest Value)
7658 lbf ft
Travel System/Drive Mechanism Travel performance: Traveling Speed - Low (XXX/)
1.6 mph
Travel System/Drive Mechanism Travel performance: Traveling Speed - High (/XXX)
2.9 mph
Weights Operating Weight
8,193 lb
Weights Standard Boom Length
8.04 ft
Weights Standard Arm Length
4.36 ft
Weights Standard Bucket Size
0.13 yd³
Weights Shoe Width
11"
Working Range Max Digging Reach (Ground)
17' 1"
Working Range Max Digging Depth
10' 2"
Working Range Max Loading Height
11' 3"
Digging Force (ISO) Arm Digging Force - Pressure up
4,859 lb
Digging Force (ISO) Bucket Digging Force - Pressure up
6,968 lb
Track Length
6' 9"
Standard Boom Length
8.04 Ft
Standard Arm Length
4.36 Ft
Standard Bucket Size
0.13 Yd³
Shoe Width
11"
Shipping Height - Hose (With Attachment)
8' 0"
Shipping Length (Without Attachment)
15' 9"
Shipping Width (Standard)
5' 9"
Overall Height Over Cab
8' 0"
Max Digging Depth
10' 2"
Max Loading Height
11' 3"
Dimensions Shipping Height - Hose (With Attachment)
8' 0"
Dimensions Shipping Length (Without Attachment)
15' 9"
Dimensions Shipping Width (Standard)
5' 9"
Dimensions Overall Height Over Cab
8' 0"
Main Pump: Max. Flow Rate (Each)
26.6 gal/min
Main Pump: Main Relief Pressure
3,553 psi
Hydraulic System Main Pump: Max. Flow Rate (each)
26.6 gal/min
Hydraulic System Main Pump: Main Relief Pressure
3,553 psi
